A Guide to using Hexadecimals for Color in R

Hexadecimals allow for specificity and flexibility.

Photo by Alexander Grey on Pexels

In R, hexadecimal (hex) color codes are commonly used to specify colors in graphics and plots. Hexadecimal codes represent colors as a combination of red, green, and blue (RGB) values, where each color is represented by a two-digit hexadecimal number ranging from 00 to FF (0 to 255 in decimal).

Stated another way, we define a color as a 6 hexadecimal digit number of the form #RRGGBB. Where the RR is for red, GG for green and BB for blue and value ranges from 00 to FF.

For example, #FF0000 would be red and #00FF00 would be green similarly, #FFFFFF would be white and #000000 would be black. The color code #0000FF represents pure blue, while##FF0000represents pure red. Here are two examples:

temp <- c(5,7,6,4,8)
barplot(temp, col="#c00000", main="#c00000") # this is the first plot
barplot(temp, col="#AA4371", main="#AA4371") # this is the second plot

We can also color each bar of the barplot with a different color by providing a vector of colors made up of hexadecimals.

If the number of colors provided is less than the number of bars, the color vector is recycled.

We can see this in the following examples:

barplot(temp, col=c("#FF0099","#CCFF00","#33FF00",
"#00FF66","#FF9900"), main="With 5 colors") # this is the first plot

barplot(temp, col=c("#FF99FF","#0066FF","#00FF4D"), main="With 3 colors")
# this is the second plot
